ZP168 Series Rotary Tablet Press

Short Description:

This machine is a new type of automatic rotary continuous tablet press, specifically designed to compress granular materials into tablets, capable of producing both round and irregularly shaped tablets. The machine features high torque and a reasonable structure, with an enlarged pressure roller shaft for smoother operation. It is suitable for laboratory trials and small-scale production, primarily used in the pharmaceutical, chemical, and food industries. The ZPT model is equipped with an upper punch with an oil ring, meeting international standards.


Product Detail

Product Tags

Main Technical Specifications

Model ZP168-15 ZP168-12 ZPT168-10D ZPT168-14B ZPT168-15 ZPT168-12
Punch Type Ф22x115 Ф26x115 Ф25.35x133.6(D) Ф19x133.6(B) Ф22x133.6 Ф26x133.6
Numbers of Punch Stations 15 12 10 14 15 12
Max Pressure (kN) 60
Max Tablet Diameter (Round shape, mm) 13 20 22 16 13 20
Max Filling Depth (mm) 15
Max Thickness of Tablet (mm) 6
Max Turret Rotation $peed(r/min) 50
Max Production Capacity (tablets/hour) 45000 36000 30000 42000 45000 36000
Electrical Supply Parameters 2.2
Dimensions(mm) 850x600x1100
weight (kg) 300

Product Details

Product Details

Punch & Die

Punch & Die 1
Punch & Die

Tablet Display

Tablet Display
